Ultrafine filter, Series MH1-FLC Aventics art. R432034654
Specifications
| Version | Microfilter |
| Parts | Microfilter |
| Mounting orientation | vertical |
| Working pressure min./max. | 0,5 ... 17 bar |
| Ambient temperature min./max. | -30 ... 80 °C |
| Medium temperature min./max. | -30 ... 80 °C |
| Medium | Compressed air Neutral gases |
| Filter element | exchangeable |
| filter porosity | 0,01 µm |
| Condensate drain | semi-automatic, open without pressure |
| Weight | See table |
| The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C . | |
| Recommended pre-filtering | 5 µm |
| Material |
|---|
| Housing | Stainless steel, acid-proof |
| Reservoir | Stainless steel, acid-proof |
| Filter insert | Borosilicate glass fiber |
