Bellows Cylinder with Reversible Bellows, BRB Series Aventics art. 1909041000
Specifications
| Version | Flexible rolling bellow |
| Functional principle | Single-acting, retracted without pressure |
| Working pressure min./max. | See table |
| Ambient temperature min./max. | -30 ... 90 °C |
| Medium | Compressed air |
| Permissible angle of tilt max. | 15 ° |
| Pressure for determining forces | 6 bar |
| Weight | See table |
| Compliance with the minimum height H min. as well as the maximum height H max. must be ensured with end stops. Use at operating height ≥ Hmax: only permitted upon approval by AVENTICS Further information on vibration isolation can be found in the “Technical information” document (available in the MediaCentre). Rolling bellows cylinders may only be moved or pushed together under pressure, otherwise this can damage the bellows. | |
| Reduced service life at a temperature greater than | 70 °C |
| Material |
|---|
| Bellow | Chloroprene rubber |
| Front cover | Polyamide fiber-glass reinforced |
| End cover | Polyamide fiber-glass reinforced |
| Piston | Polyamide fiber-glass reinforced |
| clamping ring | Aluminum Steel |
