Series MS01 Aventics art. R412006880
Specifications
| Version | Driver |
| Ambient temperature min./max. | 0 ... 50 °C |
| Operational voltage electronics | 24 V DC |
| Power consumption electronics | 0,2 A |
| Operating voltage, actuators | 24 V DC |
| Actuator voltage tolerance | -10% / +10% |
| Total current for actuators | 3 A |
| Protection class | IP65 |
| Number of solenoid coils max. | 24 |
| Max. power consumption per coil | 0,1 mA |
| Max. cable length | 40 m |
| Max. number of DDL participants | 14 |
| Port Valve system | Socket (female), 2.0 mm strip, 3x13-pin |
| I/O module extension max. | 6 |
| I/O module extension Input Max. | 3 |
| I/O module extension Output Max. | 3 |
| Weight | 1,04 kg |
| Max. current in 0 V line: 4 A You will find assignment schemes for the product in the operating instructions, or contact the nearest AVENTICS sales office. Caution: A reduced temperature range in accordance with the operating instructions may need to be considered in ATEX applications. |
| Material |
|---|
| Housing | Die-cast aluminum |
