Vacuum nozzle Aventics art. R412026137
Specifications
| Activation | pneumatically |
| Working pressure min./max. | 2 ... 6 bar |
| Working pressure p.opt. | 4 bar |
| Ambient temperature min./max. | 0 ... 60 °C |
| Medium temperature min./max. | 0 ... 60 °C |
| Medium | Compressed air |
| Max. particle size | 5 µm |
| Oil content of compressed air | 0 ... 1 mg/m³ |
| Max. vacuum level at p.opt | 82 % |
| Weight | 0,035 kg |
| Note: All data refers to an ambient pressure of 1.013 bar and an ambient temperature of 20 °C . The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C . The oil content of compressed air must remain constant during the life cycle. |
| Material |
|---|
| Housing | Polyamide |
| Seal | Acrylonitrile butadiene rubber |
| Nozzle | Brass |
