AP Series Aventics art. 0821305042
Specifications
| Version | electrical control, compact form |
| Activation | Electrically |
| Working pressure min./max. | 3 ... 6 bar |
| Ambient temperature min./max. | 0 ... 50 °C |
| Medium temperature min./max. | 0 ... 50 °C |
| Medium | Compressed air |
| Max. particle size | 5 µm |
| Oil content of compressed air | 0 ... 1 mg/m³ |
| Protection class With valve plug connector | IP65 |
| Duty cycle according to DIN VDE 0580 standard | 100 % |
| Max. vacuum level at p.opt | 83 % |
| Voltage tolerance DC | -10% / +10% |
| Weight | See table |
| Note: All data refers to an ambient pressure of 1.013 bar and an ambient temperature of 20 °C . The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C . |
| Material |
|---|
| Housing | Aluminum, anodized |
| Nozzle | Brass |
