Single mounting plate Aventics art. 8985041404
Specifications
| Standards | ISO 5599-1 |
| Compressed air connection | according to ISO 5599-1 |
| Working pressure min./max. | -0,95 ... 10 bar |
| Ambient temperature min./max. | -25 ... 70 °C |
| Medium temperature min./max. | -25 ... 70 °C |
| Medium | Compressed air |
| Number of valve positions max. | 1 |
| Grid dimension | 85 mm |
| Direction of pneumatic port (1) | On the side |
| Direction of pneumatic port (3,5) | On the side |
| Direction of pneumatic port (2,4) | On the side |
| Direction of pneumatic port (12) | On the side |
| Direction of pneumatic port (14) | On the side |
| Exhaust (3,5) | With directional exhaust (3/5) |
| Exhaust type | Ports separated |
| Weight | 0,99 kg |
| The min. control pressure must be adhered to, since otherwise faulty switching and valve failure may result! The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C . The oil content of compressed air must remain constant during the life cycle. Use only the approved oils from AVENTICS. Further information can be found in the “Technical information” document (available in the MediaCentre). |
| For use with HV series valves, the ambient temperature is -25 °C...200 °C and the medium temperature is -25 °C...120 °C. Reversed pressure supply is not permitted for HV series valves. |
| Material |
|---|
| Base plate | Die-cast aluminum |
