To receive a proposal, please send your request to info@aventics-sensors.in and specify the required positions and company details.
Pressure gauges Aventics art. R412004987
Specifications
| Version | Bourdon tube pressure gauge |
| Seal | Axial |
| Standardization | EN 837-1 |
| Class | 1,6 |
| Ambient temperature min./max. | -40 ... 60 °C |
| Medium | Compressed air |
| Main scale unit (outside) | bar |
| Main scale color (outside) | Green |
| Secondary scale unit (inside) | psi |
| Secondary scale color (inside) | White |
| Background color | Black |
| Pointer color | White |
| Weight | 0,09 kg |
| Suitable for use in Ex zones 1, 2, 21, 22. Order axial seal separately |
| Material |
|---|
| Housing | Acrylonitrile butadiene styrene |
| Thread | Brass |
| Viewing window | Mineral glass |
