Sensor Aventics art. R412022866
Specifications
| Ambient temperature min./max. | -30 ... 80 °C |
| Protection class | IP65 IP67 IP69K |
| Switching point precision | ±0,1 mT |
| Nominal current, actuated state | < 30 mA |
| Quiescent current (without load) | < 8 mA |
| Min./max. DC operating voltage | See table |
| Min./max. AC operating voltage | See table |
| Hysteresis | ≥ 0,2 mT |
| Switching logic | NO (make contact) |
| LED status display | Yellow |
| Vibration resistance | 10 - 55 Hz, 1 mm |
| Shock resistance | 30 g / 11 ms |
| Cable length L | 3 5 10 m |
| No cULus certification for 230 V variant. |
| Material |
|---|
| Housing | Polyamide |
| Cable sheath | Polyurethane |
| Locking screw | Stainless steel |
