Sensor Aventics art. R412010426
Specifications
| Standardization | DIN EN 60947-5-2 |
| Certificates | cULus |
| Ambient temperature min./max. | -20 ... 65 °C |
| Protection class | IP67 |
| Hysteresis | 5 - 15%, adjustable |
| Temperature drift | ± 10 % |
| Residual ripple | ≤ 10 % |
| Reproducibility | ≤ 2 % |
| Switching logic | NO (make contact) |
| LED status display | Yellow |
| Flush installation Switching states:1. Pressure applied to locking unit, clamping pliers are open, sensor does not emit a signal (normally open)2. No pressure applied to locking unit, clamping pliers are closed, sensor emits a signal (feedback that LU6 is clamping) |
| Material |
|---|
| Housing | Brass |
