Rodless cylinders Aventics art. R480627034
Specifications
| Working pressure min./max. | 2 ... 8 bar |
| Ambient temperature min./max. | -10 ... 60 °C |
| Medium | Compressed air |
| Max. particle size | 5 µm |
| Oil content of compressed air | 0 ... 1 mg/m³ |
| Pressure for determining piston forces | 6.3 bar |
| The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C . The delivered product is lubricated for lifetime. These pneumatic components with NPT or inch thread dimensions are only available from our US sales organization. Thread depth: 0.35 inch for piston Ø 5/8 - 1 1/2, 0.47 inch for piston Ø 5/8 - 3 Thread depth: 0.24 inch for piston Ø 5/8 - 1, 0.40 inch for piston Ø 1 1/4 - 2, 0.59 inch for piston Ø 2 1/2 - 3 Can be selected in the configurator (M7 for high-speed applications) |
| Material |
|---|
| Cylinder tube | Aluminum, anodized |
| Cap | Aluminum, anodized |
| Seal | Polyurethane |
| Sealing strips | Polyurethane Stainless steel |
| Ball rail table | Aluminum, anodized |
