Rodless cylinders Aventics art. R480146347
Specifications
| Working pressure min./max. | 2 ... 8 bar |
| Ambient temperature min./max. | -10 ... 60 °C |
| Medium | Compressed air |
| Max. particle size | 5 µm |
| Oil content of compressed air | 0 ... 1 mg/m³ |
| Pressure for determining piston forces | 6.3 bar |
| An example configuration is illustrated. The delivered product may thus deviate from the illustration. |
| The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C . The delivered product is lubricated for lifetime. Use hydraulic shock absorbers for precise end position adjustment. thread depth: 12 mm for piston Ø 16, 25 & 40 mm, 10,5 mm for piston Ø 32 thread depth: 12,7 mm for piston Ø 16–40 mm thread depth: 9 mm for piston Ø 16–40 mm thread depth: 10 mm for piston Ø 16–40 mm |
| Material |
|---|
| Cylinder tube | Aluminum, anodized |
| Cap | Aluminum, anodized |
| Seal | Polyurethane |
| Sealing strips | Polyurethane Stainless steel |
| Ball rail table | Aluminum, anodized |
| Guide rail | Steel, hardened |
