Rod end without flange, Series AP6 Aventics art. 0822062703
Specifications
| Working pressure min./max. | See table |
| Ambient temperature min./max. | -10 ... 70 °C |
| Medium | Compressed air |
| Max. particle size | 50 µm |
| Oil content of compressed air | 0 ... 5 mg/m³ |
| Pressure for determining piston forces | 6.3 bar |
| Weight | See table |
| The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C . The oil content of compressed air must remain constant during the life cycle. Use only the approved oils from AVENTICS. Further information can be found in the “Technical information” document (available in the MediaCentre). |
| Material |
|---|
| Housing | Aluminum, anodized |
| Seal | Polyurethane |
| Front plate | Steel, galvanized |
| Guide rod | Steel, hardened |
| Bearing | Steel, hardened |
| Piston rod | Stainless steel |
