Pressure regulator Aventics art. R422103085
Specifications
| Adjustment range min./max. | 0,5 ... 10 bar |
| Ambient temperature min./max. | -10 ... 60 °C |
| Medium temperature min./max. | -10 ... 60 °C |
| Medium | Compressed air |
| Weight | 0,02 kg |
| Kit for stacking assembly of up to 6 regulators: R422103090 Mounting bracket (2x) for mounting to the mounting plate: R422103091 For 2 or more AV pressure regulators assembled into blocks with pressure gauges, use of push-in fitting R412005046 is recommended for every second pressure gauge |
| Material |
|---|
| Housing | Aluminum |
| Seals | Acrylonitrile butadiene rubber |
