Pneumatic sensor Aventics art. 0820212201
Specifications
| Mounting orientation | Any |
| Working pressure min./max. | 2 ... 6 bar |
| Ambient temperature min./max. | -15 ... 60 °C |
| Medium | Compressed air |
| Max. particle size | 40 µm |
| Switching point precision | ±0,2 mT |
| Switching time on | 12 ms |
| Switching time off | 25 ms |
| Weight | 0,015 kg |
| The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C . The oil content of compressed air must remain constant during the life cycle. Use only the approved oils from AVENTICS. Further information can be found in the “Technical information” document (available in the MediaCentre). |
| Notice: This product may only be operated with oil-free, dry compressed air. |
| Material |
|---|
| Housing | Polyamide |
