Flow connector Series AV03 Aventics art. R422003050
Specifications
| Working pressure min./max. | -0,95 ... 10 bar |
| Ambient temperature min./max. | -10 ... 60 °C |
| Medium | Compressed air |
| Weight | 0,115 kg |
| When using polyurethane tubing, we recommend using additional stiffener sleeves. For push-in fittings, only use plug accessories made of plastic (polyamide) from our catalog. Pneumatic connection to base plate valves, suitable for all sizes in the AV03 and AV05 series Doubling of flow rate performance by connecting the working connections of two valves. Both valves must be identical models and controlled electrically at the same time. |
| Material |
|---|
| Housing | Aluminum |
| Seals | Nitrile rubber |
