Control valve with filter Aventics art. 9155522410
Specifications
| Version | 1-part |
| Parts | Filter pressure regulator |
| Mounting orientation | vertical |
| Working pressure min./max. | 0,5 ... 16 bar |
| Ambient temperature min./max. | -10 ... 60 °C |
| Medium temperature min./max. | -10 ... 60 °C |
| Medium | Compressed air Neutral gases |
| Nominal flow Qn | 7000 l/min |
| Regulator type | Diaphragm-type pressure regulator |
| Regulator function | with relieving air exhaust |
| Adjustment range min./max. | 0,5 ... 10 bar |
| Pressure supply | single |
| Filter reservoir volume | 300 cm³ |
| Filter element | exchangeable |
| Condensate drain | Manual |
| Weight | 2,4 kg |
| The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C . Mounting: panel installation or mounting bracket R412004873 |
| Material |
|---|
| Housing | Die-cast aluminum |
| Seals | Acrylonitrile butadiene rubber |
| Reservoir | Die-cast aluminum |
| Filter insert | Polyethylene |
