Compact ejector Aventics art. 0821305160
Specifications
| Activation | Electrically |
| Working pressure min./max. | 3 ... 6 bar |
| Ambient temperature min./max. | 0 ... 50 °C |
| Medium temperature min./max. | 0 ... 50 °C |
| Medium | Compressed air |
| Max. particle size | 5 µm |
| Oil content of compressed air | 0 ... 1 mg/m³ |
| Nozzle Ø | 1,5 mm |
| Max. suction capacity | 63 l/min |
| Air consumption at p.opt. | 116 l/min |
| Weight | 0,11 kg |
| Note: All data refers to an ambient pressure of 1.013 bar and an ambient temperature of 20 °C . The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C . The oil content of compressed air must remain constant during the life cycle. p.opt. = optimum working pressure |
| Material |
|---|
| Housing | Polyamide fiber-glass reinforced |
| Seal | Acrylonitrile butadiene rubber |
| Nozzle | Brass |
| Silencer | Polyethylene |
