5/3-pneumatic distributor Aventics art. 5777775302
Specifications
| Version | Spool valve, positive overlapping |
| Activation | Electrically |
| Pilot | Internal |
| Sealing principle | Soft sealing |
| Working pressure min./max. | 3 ... 10 bar |
| Control pressure min./max. | 3 ... 10 bar |
| Ambient temperature min./max. | See table |
| Medium temperature min./max. | See table |
| Medium | Compressed air |
| Max. particle size | 50 µm |
| Oil content of compressed air | 0 ... 1 mg/m³ |
| Nominal flow Qn | 900 l/min |
| Nominal flow 1 ▶ 2 | See table |
| Nominal flow 2 ▶ 3 | See table |
| Compressed air connection | according to ISO 228-1 |
| Pilot control exhaust | with directional pilot air exhaust |
| Connector standard | EN 175301-803:2006 |
| Reverse polarity protection | Protected against polarity reversal |
| Compatibility index | 13 14 |
| Duty cycle | 100 % |
| Mounting on manifold strip | P-strip PRS strip |
| The min. control pressure must be adhered to, since otherwise faulty switching and valve failure may result! The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C . The oil content of compressed air must remain constant during the life cycle. Use only the approved oils from AVENTICS. Further information can be found in the “Technical information” document (available in the MediaCentre). |
| ATEX optional: ATEX version can be produced by combining the basic valve without coil with an ATEX coil. ATEX ID: see ATEX coils catalog page. |
| Material |
|---|
| Housing | Die cast zinc Polyamide fiber-glass reinforced |
| Seals | Acrylonitrile butadiene rubber |
